It can cutter table sample maker plotter machine with big table/2 m x 3-3,5 m,similar to ESKO Kongsberg XP Auto ,or Zund for corrugated board / for sample maker or short run box production :
A)Cut and crease 0 mm -15 mm corrugated board /E,B,C,BC,AA,CE ,AAA flutes / ,also 15mm thickness corrugated board /triple flute corrugated board
B)cut and crease chipboard and grey cardboard - 0-3 mm
C)V cutting of paper honeycomb , triple flute corrugated board ,PP corrugated
D)cutting of PE foam 0-50 mm thickness and laminated corrugated board
E)cutting and creasing preprinted sheets for displays,POP displays.
TYPE | DCZ701310 |
Effective cutting area | 1300*1000mm |
Configuration | Oscillating blade, pen, creasing wheel, drag knife, v cut tool, 30mm foam board cutting tool |
Function | It is used in carton& paper box packaging factory. it can cut and crease 15mm corrugated paper. |
Max speed | 1350mm/s |
Smallest diameter diameter | 6mm |
Maximum cutting thickness | 20mm |
Control line and driver | Servo |
Precision | ≤0.1mm |
vacuum | 5.5kw |
Data form | HPGL |
Voltage | 220v±10% 50Hz |
Data port | Serial port, parallel port, USB port(extra tieline available) |
Data Transmission speed | 10MB/S |
Input cushion area | 32MB |
